Information for West Mesa AFS, NM

Latitude: 35-04-19 N, Longitude: 106-52-12 W

Call Sign(s): Carrot,Blush First


Perm ID Sage ID JSS ID Unit Location Early
Equip.
Final
Equip.
Oper.
Date
Inact.
Date
Notes
M-94 Z-94   687 West Mesa AFS, NM MPS-7; MPS-14; FPS-20A/-91A FPS-91A; MPS-14 1956 08-Sep-68 Site is 22 miles west of Albuquerque. Site was intended to go atop Mt. Vulcan, but owner refused to sell. West Mesa is FAA site now, using FPS-66A radar.
M-94A       Carrizozo, NM ** (none listed)
M-94B       San Antonio, NM ** (none listed)       Gap-Filler Annex. ** Not built. 1955 CONAD History document lists M-94B as San Antonio, NM. However, M-94B was eventually built at Zuni, NM (although never operational).
M-94B       Zuni, NM (none listed)       Gap-Filler Annex. 1955 CONAD History document lists the location of M-94B as San Antonio, NM. Zuni building is no longer extant. Located about 9 miles south-southeast of Zuni Pueblo. Radar tower and fuel tank were installed, but not the radar equipment due to the pending site cancellation.
M-94C       Datil, NM ** (none listed)       Gap-Filler Annex. ** Listed in early ADC history documents, but not built.

Current Use: Still active. This now-FAA long-range radar site is now data-tied into the Joint Surveillance System (post 9/11).

NOTICE:
Some photos and documents may be marked with varying degrees of classification, up to SECRET. Data so marked is the way it was delivered from official USAF sources, and have been completely declassified. To the best of our knowledge, no currently classified data is stored on this site.
