Information for Dauphin Island AFS, AL

Latitude: 30-15-00 N, Longitude: 088-04-40 W

Perm ID Sage ID JSS ID Unit Location Early
TM-196 Z-196   693 Dauphin Island AFS, AL FPS-20; FPS-6A (2); FPS-7 FPS-93A; FPS-6 * Jan-59 Sep-70 * (Site originally was planned to be located at Foley, AL.) * Re-opened in 1972 as part of the Southern Air Defense System.
TM-196A / M-126A Z-126A     New Orleans, LA FPS-14 FPS-18 Oct-57 1 July 1970 Gap-Filler Annex. The radar site was located at Camp Leroy Johnson (next to Lake Pontchartrain).
TM-196A, TM-198B Z-198B     Eglin AFB, FL FPS-14 FPS-18 Oct-59 22-Apr-70 Gap-Filler Annex. Building is still extant.
TM-196B Z-196B     Gulfport, MS FPS-18   Aug-61 01-Jul-70 Gap-Filler Annex. Site was just east of the airport, on 47th Street, between Adams Ave. and Chamberlain Ave., per USACE FUDS report.

Current Use: Dauphin Island Sea Lab. [See also Dauphin Island AFS, AL, 635th Radar Squadron (Z-249); and Dauphin Island AFS, AL, OLAG 630th Radar Squadron (Z-249).]

Some photos and documents may be marked with varying degrees of classification, up to SECRET. Data so marked is the way it was delivered from official USAF sources, and have been completely declassified. To the best of our knowledge, no currently classified data is stored on this site.
The following site information is available:
