AN/FPS-14

This medium-range search radar was designed and built by Bendix as a SAGE system gap-filler radar to provide low-altitude coverage. Operating in the S-band at a frequency between 2700 and 2900 MHz, the AN/FPS-14 could detect at a range of 65 miles. The system was deployed in the late 1950s and 1960s.


This photo is of the Saugatuck, MI Gap Filler tower and sail, before the dome was installed.


Westboro, MA FPS-14 antenna, ca 1961
